3 Phase Boom Jib Crane Light Compact Structure High Strength Bolt Connection
Product description of 3 Phase Boom Jib Crane Light Compact Structure High Strength Bolt Connection:
This is one type of wall mounted swing jib crane, easy to install and easy to control.It is widely used in workshop.
If there is column adopted in the working area, and the working radium could reach the column, the user could choose our BZQ model jib crane to save your cost.
Environment conditions of 3 Phase Boom Jib Crane Light Compact Structure High Strength Bolt Connection:
1. Power source of crane is 3-phase current, rated frequency is 50HZ, voltage 380v.
2. No explosive and corrosive gas in working environment.
3. Crane is prohibited to lift smelting metal, poisonous material and flammable explosive materials.
Features of 3 Phase Boom Jib Crane Light Compact Structure High Strength Bolt Connection:
1. Light compact structure, few demand to architecture.
2. Whole structure light, conform to the state standards.
3. The installation uses high strength bolt connection.
4. Novel structure, reasonable and simple.
5. Convenient in operation, and turn to flexible.
6. Light weight, moving flexible.
7. Inexpensive handling systems that don't require modification of the building structure in which they are being installed.
8. JIb cranes don't take up much space but they allow transporting goods on a three-dimensional plane.
9. Useful in any industrial sector: foundries, boiler works, mechanical works, paper factories, etc.
10. JIb cranes are the ideal complement for the traveling cranes used in every section of an industrial plant.
11. Jib cranes increase in autonomy and effectiveness of each workstation.
Technical parameters:
| Model | Rated load (kg) | Hoist or lower the speed(m/min) | L(mm) | R2(mm) | R1(mm) |
| BZQ0.25 | 250 | 8/2 | 5420 | 5000 | 580 |
| BZQ0.5 | 500 | 4/1 | 5430 | 5000 | 530 |
| BZQ1 | 1000 | 8/2 | 5440 | 5000 | 520 |
| BZQ2 | 2000 | 4/1 | 6340 | 5000 | 450 |
| Note: | Our product can | be designed according to user's | special | demands. |
